| 品牌：Gofoton |
供应单模、多模，多种连接器，不同尺寸的跳线。高回损，低插损的精英级产品。
| arameters | Specification | Unit | ||
| Operating Wavelength | Single Mode | 1310 / 1550 | nm | |
| Multimode | 850 | |||
| Maximum Insertion Loss | Single Mode | ≤ 0.30 | dB | |
| Single Mode Premium | ≤ 0.15 | |||
| Multimode Standard | ≤ 0.40 | |||
| Multimode Premium | ≤ 0.20 | |||
| Typical Reflectance | Single Mode PC | ≤ -45 | ||
| Single Mode SPC | ≤ -50 | |||
| Single Mode UPC | ≤ -55 | |||
| Single Mode APC | ≤ -65 | |||
| Multi-mode PC | ≤ -20 | |||
| Multi-mode SPC | ||||
| Multi-mode UPC | ||||
| Multi-mode APC | ||||
| Fiber Type | Follow PN Description | |||
| Connector Type | Follow PN Description | |||
| Length | Follow PN Description | m | ||
| Length Tolerance | L ≤ 1m | ± 50 | mm | |
| 1m < L ≤3m | ± 100 | |||
| 3m < L ≤ 10m | ± 200 | |||
| L > 10m | ± 3 | % | ||
| Jacket Type | Flat Cable / Round Cable | OFNP / OFNR | ||
| Jacket Diameter | Follow PN Description | mm | ||
| Jacket Color | Yellow | SMF G652 and G657 Fiber | ||
| Orange | OM1 62.5/125 um, OM2 50/125um | |||
| Aqua | OM3 50/125um, OM4 50/125um | |||
具体规格、参数和介绍请看以下网址。
http://welcome.gofoton.com/product/simplex-and-duplex-patch-cords/
